LiftMaster CSL24UL 24VDC High Traffic Commercial Slide Gate Operator

$2,479.00

SKU: LIF-CSL24UL Category:

Description

The LiftMaster CSL24UL is a powerful 24VDC commercial slide gate operator designed for high-traffic applications. Built for continuous-duty operation, it delivers reliable performance and dependable access control for busy commercial properties.

Technical Specs

  • Power: 120V/230V Single Phase.
  • Accessory Power: 24VDC 500mA output. Switched and unswitched power.
  • Monitored Safety Inputs: 3 mainboards, 3 optional expansion boards
  • Temperature Specifications: Without Heater: -4 degrees F (-20 degrees C) to 140 degrees F (60 degrees C); With Optional Heater (HTR): -40 degrees F (-40 degrees C) to 140 degrees F (60 degrees C)
  • UL Usage Classification: I, II, III, and IV
  • Gate Travel Speed: Approximately 12 Inches Per Second
Manufacturer’s Warranty
  • Operator Warranty: 7 Years Residential, 5 Years Commercial
  • Inherent Reversing Sensor detects obstructions and reverses the gate when closing, or stops/reverses the gate when opening
  • Security+ 2.0® On-Board Radio Receiver up to 50 remote controls (unlimited with 811LM/813LM)
  • Led Diagnostic Display simplifies installation and troubleshooting
  • myQ® Technology enables you to securely control and monitor your gate operator from anywhere.
    Wireless Dual-Gate Communication synchronizes gate opening/closing and eliminates expensive driveway trenching costs.
  • Safe and Secure. Safeguards access to property with an encrypted signal to offer extended range with Security+2.0.
  • Fire Department Compliance allows the gate to auto-open upon loss of AC power or battery depletion.
  • Manual Disconnect when unlocked allows the gate to be opened manually.
  • UL® Listed gate operators with monitored safety entrapment protection devices.
  • Battery Backup provides seamless access by providing standby power when the power is down.
  • Commercial Gear-Driven Transmission provides unsurpassed reliability.
  • Smooth start/stop operation and mid-travel reversal extend operator hardware life.
  • Recommended Cycles: Continuous Duty
  • Battery Backup: 208 Cycles
  • Security+ 2.0: Yes
  • myQ® Enabled: Yes
  • Standby Power: Up to 24 days
  • Solar Performance – Cycles per Day: Approx. 22 cycles
  • DC Motor with Smooth Start/Stop: Yes
  • Diagnostic Code Display – 2 Digit LED: Yes
  • Wireless Dual-Gate Operation: Yes
  • Optional Kit (3PHCONV)to convert an input voltage of 208/230/460/575VAC to an output voltage of 120VAC
